Motion Detection 2.0
Human-Vehicle Analysis 4-ch

Video and Audio
IP Video Input 16-ch
Incoming Bandwidth 160 Mbps
Outgoing Bandwidth 80 Mbps
HDMI Output
1-ch 4K (4096 x 2160)-30 Hz 4K (3840 x 2160)-30 Hz 2K (2560 x 1440)-60 Hz 1920 x
1080-60 Hz 1600 x 1200-60 Hz 1280 x 1024-60 Hz 1280 x 720-60 Hz
VGA Output 1-ch 1920 × 1080-60 Hz 1280 × 1024-60 Hz 1280 × 720-60 Hz
Video Output Mode HDMI-VGA simultaneous output
Audio Output 1-ch RCA (Linear 1 KO)
Two-Way Audio 1-ch RCA (2.0 Vp-p 1 k O)

Decoding
Decoding Format H.265+H.265H.264+H.264
Recording Resolution 8 MP-6 MP-5 MP-4 MP-3 MP-1080p-UXGA -720p-VGA-4CIF-DCIF- 2CIF-CIF-QCIF
Synchronous playback 16-ch
Decoding Capability
1-ch@8 MP (30 fps)-3-ch@4 MP (30 fps)-6-ch@1080p (30 fps)
*: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
Stream Type Video Video - Audio
Audio Compression G.711ulaw-G.711alaw-G.722-G.726

Network
Remote Connection 32
API ONVIF (profile S-G); SDK; ISAPI
Network Protocol
TCP-IP DHCP IPv4 IPv6 DNS DDNS NTP RTSP SADP SMTP SNMP NFS iSCSI ISUP
UPnP™ HTTP HTTPS
Network Interface 1 RJ-45 10-100-1000 Mbps self-adaptive Ethernet interface

PoE
Interface 16 RJ-45 10-100 Mbps self-adaptive Ethernet interface
Power = 150 W
Standard IEEE 802.3 af-at

Auxiliary Interface
SATA 2 SATA interfaces
Capacity Up to 8 TB capacity for each disk
Alarm In-Out N-A (4-1 is optional)
USB Interface 2 × USB 2.0

General
Power Supply 100 to 240 VAC 50 to 60 Hz
Consumption = 15 W (without HDD and PoE off)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10-por-ciento to 90-por-ciento
Chassis 1U chassis
Dimension (W × D × H) 385 × 315 × 52 mm (15.2a× 12.4a × 2.0a)
Weight = 2.6 kg (without HDD 5.7 lb.)
