Camera
Image Sensor 1-2.8a Progressive Scan CMOS
Max. Resolution 1920 × 1080
Min. Illumination Color: 0.001 Lux @ (F1.0 AGC ON) 0 Lux with light
Shutter Time 1-3 s to 1-100000 s
Day - Night 24-7 color imaging
Angle Adjustment Pan: 0° to 360° tilt: 0° to 75° rotate: 0° to 360°

Lens
Lens Type Fixed focal lens 2.8 and 4 mm optional
Focal Length - FOV
2.8 mm horizontal FOV: 106° vertical FOV: 57° diagonal FOV: 126°
4 mm horizontal FOV: 83° vertical FOV: 44° diagonal FOV: 99°
Lens Mount M12
Iris Type Fixed
Aperture F1.0
Depth of Field
2.8 mm: 1.5 m to 8
4 mm: 2.1 m to 8

DORI
2.8 mm D: 44 m O: 17 m R: 8 m I: 4 m
4 mm D: 56 m O: 22 m R: 11 m I: 5 m
Illuminator
Supplement Light Type White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes

Video
Main Stream
50 Hz: 25 fps (1920 × 1080 1280 × 720)
60 Hz: 30 fps (1920 × 1080 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480 640 × 360)
60 Hz: 30 fps (640 × 480 640 × 360)
Video Compression
Main stream: H.265+-H.265-H.264+-H.264
Sub-stream: H.265-H.264-MJPEG
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile Main Profile High Profile
H.265 Type Main Profile
Bit Rate Control CBR VBR
Region of Interest (ROI) 1 fixed region(s) for main stream

Audio
Audio Type -U: Mono sound
Environment Noise Filtering -U: Yes
Audio Sampling Rate -U: 8 kHz-16 kHz
Audio Compression -U: G.711ulaw-G.711alaw-G.722.1-G.726-MP2L2-PCM-AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711 ulaw)-64 Kbps (G.711 alaw)-16 Kbps (G.722.1)-16 Kbps (G.726)-32
to 160 Kbps (MP2L2)-16 to 64 Kbps (AAC-LC)

Network
Protocols
TCP-IP ICMP DHCP DNS HTTP RTP RTSP NTP IGMP IPv6 UDP QoS FTP SMTP
SSL-TLS
Simultaneous Live View Up to 6 channels
API
Open Network Video Interface (Profile S Profile T Profile G (only -F model supports))
ISAPI SDK
User-Host
Up to 32 users
3 user levels: administrator operator and user
Security
Password protection complicated password watermark basic and digest
authentication for HTTP WSSE and digest authentication for Open Network Video
Interface security audit log host authentication (MAC address)
Client iVMS-4200 Hik-Connect
Web Browser
Plug-in required live view: IE 10 IE 11
Local service: Chrome 57.0+ Firefox 52.0+

Wide Dynamic Range (WDR) Digital WDR
SNR = 52 dB
Day-Night Switch Day Night Auto Schedule
Image Enhancement BLC HLC 3D DNR
Image Settings
Rotate mode saturation brightness contrast sharpness gain white balance
adjustable by client software or web browser
Privacy Mask 4 programmable polygon privacy masks

Interface
Ethernet Interface 1 RJ45 10 M-100 M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot support microSD-microSDHC-microSDXC card up to 256 GB
Built-in Microphone -U: Yes
Reset Key -F: Yes

Event
Basic Event
Motion detection (support alarm triggering by specified target types (human and
vehicle)) video tampering alarm exception
Linkage
Upload to FTP-memory card (-F) notify surveillance center send email trigger
recording (-F) trigger capture

General
Power
12 VDC ± 25-por-ciento 0.4 A max. 5 W Ø 5.5 mm coaxial power plug
PoE: 802.3af Class 3 36 V to 57 V 0.2 A to 0.15 A max. 6.5 W
Material Metal - Plastic
Dimension Ø 109.9 mm × 103.6 mm (Ø 4.3a × 4.1a)
Package Dimension 150 mm × 150 mm × 141 mm (5.9a × 5.9a × 5.6a)
Weight
-L: Approx. 370 g (0.8 lb.)
-LUF: Approx. 380 g (0.8 lb.)
With Package Weight
-L: Approx. 600 g (1.3 lb.)
-LUF: Approx. 620 g (1.4 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95-por-ciento or less (non-condensing)
Startup and Operating
Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95-por-ciento or less (non-condensing)
Language English Ukrainian
General Function Heartbeat anti-banding mirror password protection password reset via email

Approval
EMC
FCC: 47 CFR Part 15 Subpart B
CE-EMC: EN 55032: 2015 EN 61000-3-2:2019 EN 61000-3-3: 2013 + A1: 2019 EN
50130-4: 2011 + A1: 2014
RCM: AS-NZS CISPR 32: 2015
KC: KN32: 2015 KN35: 2015
Safety
UL: UL 62368-1
CB: IEC 62368-1: 2014 + A11
CE-LVD: EN 62368-1: 2014-A11: 2017
BIS: IS 13252 (Part 1): 2010-IEC 60950-1: 2005
Environment
CE-RoHS: 2011-65-EU
WEEE: 2012-19-EU
Reach: Regulation (EC) No 1907-2006
Protection IP67: IEC 60529-2013
