Camera
Image Sensor 1-3 Progressive Scan CMOS
Min. Illumination Color: 0.005 Lux @ (F1.6 AGC ON) 0 Lux with IR on
Shutter Speed 1-3 s to 1-100000 s
Slow Shutter Yes
P-N P-N
Wide Dynamic Range 120 dB
Day - Night ICR Cut
Angle Adjustment Pan: 0° to 360° tilt: 0° to 90° rotate: 0° to 360°

Lens
Lens Type - FOV
2.8 mm horizontal FOV 103° vertical FOV 55° diagonal FOV 122°
4 mm horizontal FOV 84° vertical FOV 45° diagonal FOV 100°
6 mm horizontal FOV 52° vertical FOV 28° diagonal FOV 61°
Aperture F1.6
Lens Mount M12

DORI
2.8 mm: D: 67 m O: 26 m R: 13 m I: 6 m
4 mm: D: 80 m O: 31 m R: 16 m I: 8 m
6 mm: D: 120 m O: 47m R: 24m I: 12 m
Illuminator
IR Range Up to 40 m
Wavelength 850 nm
Video
Max. Resolution 2688 × 1520
Main Stream
50Hz: 25fps (2688 × 1520 1920 × 1080 1280 × 720)
60Hz: 30fps (2688 × 1520 1920 × 1080 1280 × 720)
Sub Stream
50Hz: 25 fps (1280 × 720 640 × 480 640 × 360)
60Hz: 30 fps (1280 × 720 640 × 480 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080 1280 × 720 640 × 480 640 × 360)
60 Hz: 10 fps (1920 × 1080 1280 × 720 640 × 480 640 × 360)
Video Compression
Main stream: H.265-H.264-H.264+-H.265+
Sub-stream: H.265-H.264-MJPEG
Third stream: H.265-H.264
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile-Main Profile-High Profile
H.265 Type Main Profile
H.264+ Main Stream supports
H.265+ Main Stream supports
Bit Rate Control CBR-VBR
Scalable Video Coding (SVC) Yes
Region of Interest (ROI) 1 fixed region for main stream and sub-stream

Audio
Environment Noise Filtering -U: Yes
Audio Sampling Rate -U: 8 kHz-16 kHz-32 kHz-44.1 kHz-48 kHz
Audio Compression -U: G.711ulaw-G.711alaw-G.722.1-G.726-MP2L2-PCM-MP3-AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw-G.711alaw)-16 Kbps (G.722.1)-16 Kbps (G.726)-16-64 Kbps
(AAC-LC)

Network
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S Profile G) ISAPI SDK
Protocols
TCP-IP ICMP HTTP HTTPS FTP DHCP DNS DDNS RTP RTSP NTP UPnP SMTP
IGMP 802.1X QoS IPv6 UDP Bonjour SSL-TLS PPPoE WebSocket WebSockets
User-Host Up to 32 users. 3 user levels: administrator operator and user
Security
Password protection complicated password HTTPS encryption IP address filter
Security Audit Log basic and digest authentication for HTTP-HTTPS TLS 1.1-1.2 WSSE
and digest authentication for Open Network Video Interface
Network Storage NAS (NFS SMB-CIFS) auto network replenishment (ANR)
Client iVMS-4200 Hik-Connect Hik-Central
Web Browser
Plug-in required live view: IE 10 IE 11
Plug-in free live view : Chrome 57.0+ Firefox 52.0+
Local service: Chrome 57.0+ Firefox 52.0+

Day-Night Switch Day Night Auto Schedule
Image Enhancement BLC HLC 3D DNR
Image Parameters Switch Yes
Image Settings
Rotate mirror privacy mask saturation brightness contrast sharpness gain white
balance adjustable by client software or web browser

Interface
Built-in Microphone -U: Yes
On-board Storage Built-in microSD up to 512 GB
Hardware Reset Yes
Communication Interface 1 RJ45 10M-100M self-adaptive Ethernet port

Event
Basic Event
Motion detection (human and vehicle targets classification) video tampering alarm
exception
Face Detection Yes

Deep Learning Function
Perimeter Protection
Line crossing detection intrusion detection
Supports human and vehicle targets classification

General
Linkage Method
Upload to FTP-memory card-NAS notify surveillance center trigger record trigger
capture
Web Client Language
33 languages
English Russian Estonian Bulgarian Hungarian Greek German Italian Czech Slovak
French Polish Dutch Portuguese Spanish Romanian Danish Swedish Norwegian
Finnish Croatian Slovenian Serbian Turkish Korean Traditional Chinese Thai
Vietnamese Japanese Latvian Lithuanian Portuguese (Brazil) Ukrainian
General Function Anti-flicker heartbeat password reset via e-mail pixel counter
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95-por-ciento or less (non-condensing)
Startup and Operating
Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95-por-ciento or less (non-condensing)
Power Supply
12 VDC ± 25-por-ciento reverse polarity protection
PoE: (802.3af 36 V to 57 V) Class 3
Power Consumption and
Current
12 VDC 0.5 A max. 6 W
PoE (802.3af 36 V to 57 V) 0.2 A to 0.13 A max. 7 W
Power Interface Ø 5.5 mm coaxial power plug
Camera Dimension Ø70 × 161.7 mm (Ø2.76 × 6.37)
Package Dimension 216 × 121 × 118 mm (8.6a × 4.8a × 4.7a)
Camera Weight Approx. 490 g (1.1 lb.)
With Package Weight Approx. 724 g (1.6 lb.)

Approval
EMC
FCC (47 CFR Part 15 Subpart B); CE-EMC (EN 55032: 2015 EN 61000-3-2: 2014 EN
61000-3-3: 2013 EN 50130-4: 2011 +A1: 2014); RCM (AS-NZS CISPR 32: 2015); IC
(ICES-003: Issue 6 2016); KC (KN 32: 2015 KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-
1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment CE-RoHS (2011-65-EU); WEEE (2012-19-EU); Reach (Regulation (EC) No 1907-2006)
Protection IP67 (IEC 60529-2013)
