GPU
AMD Radeon™ RX 7700 XT Graphics Card
5nm GPU
AMD RDNA™ 3 Architecture
Engine Clock
Boost Clock: Up to 2544 MHz
Game Clock: Up to 2171 MHz
Stream Processors: 3456
Compute Units: 54 CU (with RT+AI Accelerators)
Infinity Cache: 48MB
Ray Accelerators: 54
Memory Size-Bus: 12GB-192 bit GDDR6
Memory Clock: 18 Gbps Effective
Displays: Maximum 4 Displays
Resolution: HDMI™: 7680×4320 - DisplayPort 2.1: 7680×4320
Interface: PCI-Express 4.0 x16
Output: 2x HDMI - 2x DisplayPort
BIOS Support: UEFI
Game Index: 1440P
Cooler Type: 2 Fans
Form Factor: 2.5 slot ATX
Dimension: 280(L)X 128.75(W)X 52.57 (H)mm
Power Consumption: 230W Total Board Power
System Requirement
Minimum 700 Watt Power Supply
2 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.
