PERFORMANCE
Processor
Intel® Core™ i7-1165G7 (4C - 8T 2.8 - 4.7GHz 12MB)
Graphics
Integrated Intel Iris® Xe Graphics functions as UHD Graphics
Chipset
Intel SoC Platform
Memory
1x 8GB SO-DIMM DDR4-3200
Memory Slots
Two DDR4 SO-DIMM slots dual-channel capable
Max Memory
Up to 64GB DDR4-3200
Storage
256GB SSD M.2 2280 PCIe 3.0x4 NVMe Opal
Storage Support
One SSD mode: one drive 1x M.2 SSD
• M.2 2280 SSD up to 1TB
• M.2 2242 SSD up to 128GB
Card Reader
MicroSD Reader
Optical
None
Audio Chip
High Definition (HD) Audio Realtek® ALC3287 codec
Speakers
Stereo speakers 2W x2 Dolby® Audio™ Premium
Camera
720p with Privacy Shutter
Microphone
2x Array
Battery
Integrated 45Wh
Max Battery Life
MobileMark® 2018: 7.53 hr
JEITA 2.0: 11.255 hr
Power Adapter
65W USB-C (2-pin)
DESIGN
Display
15.6a HD (1366x768) TN 220nits Anti-glare
Touchscreen
None
Keyboard
Non-backlit Spanish (LA)
Case Color
Black
Case Material
PC + ABS (Top) PC + ABS (Bottom)
Dimensions (WxDxH)
366.5 x 250 x 21 mm (14.43 x 9.84 x 0.83 inches)
Weight
1.98 kg (4.37 lbs)
SOFTWARE
Operating System
None
Bundled Software
None
CONNECTIVITY
Ethernet
100-1000M
WLAN + Bluetooth®
RTL8852AE 11ax 2x2 + BT5.2
WWAN
None
SIM Card
None
NFC
None
Standard Ports
• 1x HDMI® 2.0
• 1x USB 3.2 Gen 1
• 1x Side docking connector
1x USB-C 3.2 Gen 1 (support data transfer Power Delivery
3.0 and DisplayPort™ 1.4)
•
• 1x USB 3.2 Gen 1 (Always On)
• 1x Ethernet (RJ-45)
• 1x microSD card reader
1x Thunderbolt™ 4 - USB4™ 40Gbps (support data
transfer Power Delivery 3.0 and DisplayPort 1.4)
•
• 1x Headphone - microphone combo jack (3.5mm)
Monitor Cable
None
