SERIES
MasterBox Series

SIZE
Mid Tower

MATERIALS
Steel Plastic Tempered Glass Mesh

DIMENSIONS (L X W X H)
493 x 217 x 469mm (incl. Protrusions) 429.5 x 205x 447mm (excl. Protrusions)

WEIGHT
6.95 kg

MOTHERBOARD SUPPORT
Mini ITX Micro ATX ATX SSI CEB E-ATX* (*support for up to 12a x 10.7a will limit cable management features)

EXPANSION SLOTS
7

5.25a DRIVE BAYS
N-A

2.5a - 3.5a DRIVE BAYS (COMBO)
2

2.5a DRIVE BAYS
4 (2+2 combo)

I-O PANEL
2x USB 3.2 Gen 1 (formerly USB 3.0) 1x 3.5mm Audio Jack 1x 3.5mm Mic Jack 1x ARGB Controller (only for the S01 versions) 1x ARGB 2-to-3 splitter

PRE-INSTALLED FANS - FRONT
3x 120mm ARGB Fans

FAN SUPPORT - TOP
3x 120mm 2x 140mm
FAN SUPPORT - FRONT
3x 120mm 2x 140mm
FAN SUPPORT - REAR
1x 120mm

RADIATOR SUPPORT - TOP
120mm 240mm 360mm (44mm max motherboard component height)
RADIATOR SUPPORT - FRONT
120mm 140mm 240mm 280mm 360mm
RADIATOR SUPPORT - REAR
120mm

CLEARANCE - CPU COOLER
165mm-6.49a
CLEARANCE - PSU
180mm-7.08a 295mm-11.61a (w- HDD cage removed)
CLEARANCE - GFX
410mm-16.1a

CABLE ROUTING
19mm-0.74a

DUST FILTERS
Top Bottom Front

POWER SUPPLY SUPPORT
Bottom mount ATX
