WATTS 850W
FORM FACTOR ATX
MODEL TTP-850AH3FCG
MAX. OUTPUT CAPACITY 850W
PEAK OUTPUT CAPACITY 1020W
COLOR Black
DIMENSION ( W - H - D ) 150mm(W) x 86mm(H) x 160mm(D)
PFC (POWER FACTOR CORRECTION) Active PFC
POWER GOOD SIGNAL 100-500 msec
HOLD UP TIME > 16msec at 100-por-ciento of full load
INPUT CURRENT 12A
INPUT FREQUENCY RANGE 50Hz - 60Hz
INPUT VOLTAGE 100V – 240V~
OPERATING TEMPERATURE 0°C to + 50°C
OPERATING HUMIDITY 20-por-ciento to 90-por-cientonon-condensing
STORAGE TEMPERATURE -20°C to + 70°C
STORAGE HUMIDITY 5-por-ciento to 95-por-ciento non-condensing
COOLING SYSTEM 14cm hydraulic bearing fan
EFFICIENCY Meet 80 PLUS®Gold at 115Vac input.
MTBF 120000 hrs minimum
SAFETY APPROVAL CE-cTUVus-TÜV SÜD-FCC-BSMI-EAC
PCI-E 6+2PIN 6
PROTECTION OCP OVP UVP OPP SCP OTP
