Form Factor M.2 2280
Interface PCIe Gen4x4
Performance up to 7400MB-s read 5800MB s write1
IOPS: up to R-W 400-750K
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Dimension (L x W x H) 80 x 22 x 2.45 mm - 3.15” x 0.87” x 0.10”
Weight 9g
Shock Resistant 1500 G duration 0.5ms Half Sine Wave
Vibration Resistant 10~2000Hz 1.5mm 20 G 1 Oct-min 30min-axis(XYZ)
TBW 3000TB
NAND flash 3D TLC
MTBF 1500000 Hours
