• CASE TYPE Mid Tower
• Dimension (H x W x D) 503 x 287 x 485mm
• PANEL 4mm Tempered Glass x 1
• MATERIAL SPCC
• COOLING SYSTEM Rear (exhaust): 120 x 120 x 25 mm CT120 fan (500~2000rpm 25.8 dBA) x 2
• Drive Bays 2 x 3.5” - 1 x 2.5” or 3 x 2.5”
• EXPANSION SLOTS 7(Rotatable Patented Design)
• MOTHERBOARDS (Mini ITX) - (Micro ATX) - (ATX)
• Hidden-Connector Motherboard 9.6” x 9.6” (Micro ATX) 12” x 9.6” (ATX)
• I-O Port USB 3.2 (Gen 2) Type-C x 1 USB 3.0 x 2 HD Audio x 1
• PSU Standard PS2 PSU (optional)
FAN SUPPORT
• Front: 3 x 120mm - 2 x 140mm - 2 x 200mm
• Right: 3 x 120mm
• Rear: 2 x 120mm
• Bottom: 3 x 120mm
RADIATOR SUPPORT
• Front Side(AIO): 1 x 360mm - 1 x 240mm - 1 x 120mm - 1 x 280mm - 1 x 140mm
• Right Side(AIO): 1 x 360mm - 1 x 240mm - 1 x 120mm
CLEARANCE
• CPU cooler height limitation: 160mm
• VGA length limitation: 390mm with Radiator -420mm without Radiator
• PSU length limitation: 200mm (with 2.5” SSD) -260mm (without 2.5” SSD)
