Model MPE-A501-AFCAG
ATX Version ATX 12V V2.52
PFC Active PFC
Input Voltage 100-240V
Input Current 13-6A
Input Frequency 47-63Hz
Dimensions (L x W x H) 180 x 150 x 86 mm
Fan Size 140mm
Fan Bearing FDB
Fan Speed 2200 RPM
Noise Level @ 20-por-ciento 0 dBA
Noise Level @ 50-por-ciento 14.9 dBA
Noise Level @ 100-por-ciento 27.3 dBA
Efficiency =90-por-ciento @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0-50°C
Power Good Signal 100 - 150 ms
Hold Up Time >20ms at 100-por-ciento Load
MTBF >100000 Hours
Protections OVP UVP OPP OTP SCP OCP
Regulatory TUV cTUVus CE BSMI FCC CCC EAC RCM CB UKCA
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4 Pin Connectors 4
PCI-e 6+2 Pin Connectors 6
Series MWE Gold Series
80 Plus Gold
Modular Full Modular
