Interface PCI-Express 4.0x4 NVMe 1.3
Form Factor M.2 2280
Total Capacity 1000GB
Warranty Limited 5-years or 1800TBW
NAND 3D TLC NAND Flash
External DDR Cache DDR4 1GB
Sequential Read speed Up to 5000 MB-s
Sequential Write speed Up to 4400 MB-s
Random Read IOPS up to 750k
Random Write IOPS up to 700k
Dimension 80 x 22 x 2.3 mm
Mean time between failure (MTBF) 1.77 million hours
Power Consumption (Active) Average: R : 6.6W; W : 6.4W
Power Consumption (Idle) 18.8mw
Temperature (Operating) 0°C to 70°C
Temperature (Storage) -40°C to 85°C
